DIY Outdoor Kitchen Bar Height Diagonal Corner Module with Sink/Counter Top Support Kit

ALUMINUM 1" x 1" Square tubes

reg price $849.99 sale price $425.99

This is our famous diy outdoor kitchen 32" Diagonal Corner module used for large L or U Island BBQ Designs.

This is a big bbq island module and is best for large patios only.

Now  with Aluminum tubes and welded connectors it is much easier and stronger than our old stud and track version.

This is our bar height version which is nice for light weight Pizza Ovens.

note: heavy pizza ovens over 300 lbs should add our HEAVY DUTY Vertical Tubes plus our reinforcement kit

DIY Outdoor Kitchen Diagonal Corner Module Kit MEASUREMENTS

46 1/2 x 46 1/2 on the 2 rear sides

31 1/2" one the 2 ends where straight modules will connect.

The front diagonal is approx 18" and best fits a 14x20 vertical door to access plumbing for sink or egg soot opening.

41" height

Includes:

4ea Length Aluminum Tubes 43 3/4" x 25mm (Red paint)

4ea Length Aluminum Tubes 30 3/4" x 25mm (Red paint)

2ea 21mm Diagonal Front Tubes

9ea Bar Height Vertical Tubes (Black paint) (2 of these BH VTs are for a door at the angle)

6ea 3 way corner couplers

10ea One Way Couplers (Standard with both wings)

4ea One Way Couplers (For tight spaces with one wing)

Sink / Countertop Kit for Outdoor Kitchen Diagonal Corner Module

2ea 45 Degree Couplers

6ea one way couplers

2ea 4ft x 25mm tubes

2 each CTT

Not Included: Actual outdoor kitchen appliances, cement board, screws, vents, leveling feet , etc...

It does not include the egg smoker platform to support an outdoor kitchen smoker. (sold separate)
